Description

DESCRIPTIONS SPECIFICATIONS PRODUCT:

Height             : 668 mm (26.3″)
Width              : 404 mm (15.9″)
Depth              : 343 mm (13.5″)
Air Inlet          : 19 mm (3/4″ FNPT)
Liquid Inlet    : 51 mm (2″)
Liquid Outlet : 51 mm (2″)

WETTED MATERIAL: SHIP WEIGHT:

Aluminium                           33 Kg (72 lbs)
Cast Iron                               52 Kg (114 lbs)
Stainless Steel                      49 Kg (106 lbs)
Alloy C                                   53 Kg (116 lbs)

ELASTOMERS:

Neoprene                             Teflon PTFE
Nordel                                  Wil-flex
Buna-N                                Saniflex
Viton                                    Polyurethane

PERFORMANCE:

Max. Flow                       : Rubber/TPE 617 lpm (163 gpm)
Teflon 534 lpm (141 gpm)
Max. Pressure                : 8.6 bar (125 psig)
Max. Solids Passage      : 6.4 mm (1/4″)
Max. Suction Lift (wet) : Rubber/TPE 9.5 m (31.0′)
Teflon 9.5 m (31.0′)
(dry) : Rubber/TPE 6.4 m (21.0′)
Teflon 3.7 m (12.0′)
