Description
Receive external control signal, adjust the length of metering pump stroke, Thus changes the metering pump output flow.
G series metering pump chooses HE type. Among them, the GB series can choose ECC explosion-proof type.
• frequency conversion controller
Receive external control signal, adjust the speed of metering pump stroke.
Power supply: 380V/50Hz three-phase /220V/50Hz single-phase
Control signal: 4~20mA
• VARIPULSE controller:
Used for GM series metering pump, used for controlling three-phase motor,
Change the stroke frequency, so as to adjust the output flow of metering pump.
Model table of mitron GB series mechanical diaphragm pump:
| Model | Flow （l/h） | Pressure （bar） | Motor power | Pump head |
| GB0080 | 82 | 10 | 0.55KW/0.75KW | PVC /PVDF /316Stainless steel |
| GB0180 | 167 | 10 | ||
| GB0250 | 237 | 10 | ||
| GB0350 | 334 | 10 | ||
| GB0450 | 416 | 10 | ||
| GB0500 | 464 | 7 | ||
| GB0600 | 583 | 7 | ||
| GB0700 | 656 | 3.5 | ||
| GB1000 | 946 | 3.5 | ||
| GB1200 | 1200 | 3.5 | 0.75KW | |
| GB1500 | 1500 | 3 | ||
| GB1800 | 1800 | 3 |
